HEF4017BT,653 5-Stage Johnson Counter Logic Integrated Circuit Chip

HEF4017BT,653 5-Stage Johnson Counter Logic Integrated Circuit Chip

  • HEF4017BT,653 5-Stage Johnson Counter Logic Integrated Circuit Chip
  • HEF4017BT,653 5-Stage Johnson Counter Logic Integrated Circuit Chip
HEF4017BT,653 5-Stage Johnson Counter Logic Integrated Circuit Chip
Product Details:
Place of Origin: CN
Brand Name: ERIA
Certification: CE
Model Number: HEF4017BT,653
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Price: negotiable
Packaging Details: Tape and Reel
Delivery Time: 1-2 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10Kpcs per year
Contact Now
Detailed Product Description
Goods Condition: Brand New Part Status: Active
Lead Free / Rohs: Complaint Function: Logic IC
Mounting Type: Surface Mount Package: SOP16
High Light:

resolver to digital converter ic

,

ic electrical component

,

HEF4017BT 653 Integrated Circuit Chip

HEF4017BT,653 5-stage Johnson counter logic integrated circuit chip



DESCRIPTION

The HEF4017B is a 5-stage Johnson decade counter with ten spike-free decoded active HIGH outputs (Oo to O9), an active LOW output from the most significant flip-flop (O5-9), active HIGH and active LOW clock inputs (CP0, CP1) and an overriding asynchronous master reset input (MR). The counter is advanced by either a LOW to HIGH transition at CP0 while CP1 is LOW or a HIGH to LOW transition at CP1 while CP0 is HIGH (see also function table). When cascading counters, the O5-9 output, which is LOW while the counter is in states 5, 6, 7, 8 and 9, can be used to drive the CP0 input of the next counter.

A HIGH on MR resets the counter to zero (Oo = O5-9 = HIGH; O1 to O9 = LOW) independent of the clock inputs (CP0, CP1). Automatic code correction of the counter is provided by an internal circuit: following any illegal code the counter returns to a proper counting mode within 11 clock pulses. Schmitt-trigger action in the clock input makes the circuit highly tolerant to slower clock rise and fall times.



Categories Integrated Circuits (ICs)
Logic - Counters, Dividers
Manufacturer Nexperia USA Inc.
Series 4000B
Packaging ? Tape & Reel (TR) ?
Part Status Active
Logic Type Counter, Decade
Direction Up
Number of Elements 1
Number of Bits per Element 10
Reset Asynchronous
Timing -
Count Rate 30MHz
Trigger Type Positive, Negative
Voltage - Supply 4.5V ~ 15.5V
Operating Temperature -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package 16-SO
Base Part Number 4017
