RF Quadrature Modulator Ic Electrical Component Low Noise Single Supply TRF370417IRGET 50-MHz TO 6-GHz

RF Quadrature Modulator Ic Electrical Component Low Noise Single Supply TRF370417IRGET 50-MHz TO 6-GHz

  • RF Quadrature Modulator Ic Electrical Component Low Noise Single Supply TRF370417IRGET 50-MHz TO 6-GHz
RF Quadrature Modulator Ic Electrical Component Low Noise Single Supply TRF370417IRGET 50-MHz TO 6-GHz
Product Details:
Place of Origin: CHINA
Brand Name: Texas Instruments
Certification: ROHS
Model Number: TRF370417IRGET
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: negotiate
Packaging Details: 250PCS/Standard Package
Delivery Time: 2-3 working days
Payment Terms: Western Union, T/T,Paypal
Supply Ability: Consultation
Contact Now
Detailed Product Description
Function: Modulator LO Frequency: 50MHz ~ 6GHz
RF Frequency: 50MHz ~ 6GHz Voltage - Supply: 4.5V ~ 5.5V
High Light:

resolver to digital converter ic

,

integrated circuit chip

TRF370417IRGET 50-MHz TO 6-GHz RF QUADRATURE MODULATOR Low noise Single Supply.

APPLICATIONS

•Cellular Base Station Transceiver

•CDMA: IS95, UMTS, CDMA2000, TD-SCDMA

•TDMA: GSM, IS-136, EDGE/UWC-136

•Multicarrier GSM

•WiMAX: 802.16d/e

•3GPP: LTE

•Point-to-Point (P2P) Microwave

•Cable Modem Termination System (CMTS)

•Communication-System Testers

•Wideband Software-Defined RadioMHz

•Public Safety: TETRA/APC025

FEATURES

•76-dBc Single-Carrier WCDMA ACPR at –8

dBm Channel Power

•Low Noise Floor: –162.3 dBm/Hz at 2140 MHz

•OIP3 of 26.5 dBm at 2140 MHz

•P1dB of 12 dBm at 2140 MHz

•Carrier Feedthrough of –38 dBm at 2140 MHz

•1.7-V CM at I, Q Baseband Inputs

•Silicon Germanium Technology

•Side-Band Suppression of –50 dBc at 2140

•Single Supply: 4.5-V–5.5-V Operation

Function Modulator
LO Frequency 50MHz ~ 6GHz
RF Frequency 50MHz ~ 6GHz
P1dB 12dBm
Noise Floor -162dBm/Hz
Output Power -
Current - Supply 205mA
Voltage - Supply 4.5V ~ 5.5V
Test Frequency 2.14GHz
