| Place of Origin: | CHINA |
| Brand Name: | Fairchild Semiconductor |
| Certification: | ROHS |
| Model Number: | FAN8303MX |
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | negotiate |
| Packaging Details: | 2500PCS/Standard Package |
| Delivery Time: | 2-3 working days |
| Payment Terms: | Western Union, T/T,Paypal |
| Supply Ability: | Consultation |
| Function: | Step-Down | Output Configuration: | Positive |
|---|---|---|---|
| Output Type: | Adjustable | ||
| High Light: | resolver to digital converter ic,integrated circuit chip |
||
FAN8303MX Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 2A 8-SOIC
Features
2A Output Current
0.22Ω Internal Power MOSFET Switch
Wide 5V to 23V Operating Input Range
Output Adjustable from 0.6 to 20V
Stable with Low ESR Output Ceramic Capacitors
Up to 90% Efficiency
Less than 40µA Shutdown Current
Fixed 370kHz Frequency
Thermal Shutdown with Hysteresis
Cycle-by-Cycle Over-Current Protection
Available in 8-Pin SOIC Package
Applications
Set-Top Box
DSL and Cable Modems
Distributed Power Systems
Consumer Appliances (DVD)
Auxiliary supplies
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 5V |
| Voltage - Input (Max) | 23V |
| Voltage - Output (Min/Fixed) | 0.6V |
| Voltage - Output (Max) | 20V |
| Current - Output | 2A |
| Frequency - Switching | 370kHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
