TO-220AC Switching Regulator IC MUR1560G 1560G Diode Standard 600V 15A Through Hole

TO-220AC Switching Regulator IC MUR1560G 1560G Diode Standard 600V 15A Through Hole

  • TO-220AC Switching Regulator IC MUR1560G 1560G Diode Standard 600V 15A Through Hole
TO-220AC Switching Regulator IC MUR1560G 1560G Diode Standard 600V 15A Through Hole
Product Details:
Place of Origin: CHINA
Brand Name: ON Semiconductor
Certification: ROHS
Model Number: MUR1560G
Payment & Shipping Terms:
Minimum Order Quantity: 30pcs
Price: negotiate
Packaging Details: 50PCS/Standard Package
Delivery Time: 2-3 working days
Payment Terms: Western Union, T/T,Paypal
Supply Ability: Consultation
Contact Now
Detailed Product Description
Diode Type: Standard Voltage - DC Reverse: 600V
Current - Average Rectified: 15A Operating Temperature: -65°C ~ 175°C
High Light:

resolver to digital converter ic

,

ic electrical component

MUR1560G 1560G Diode Standard 600V 15A Through Hole TO-220AC switching regulator ic

Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Max) @ If 1.5V @ 15A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 60ns
Current - Reverse Leakage @ Vr 10µA @ 600V
Capacitance @ Vr, F -
Mounting Type Through Hole
Package / Case TO-220-2

Features

• Ultrafast 35 and 60 Nanosecond Recovery Time

• 175°C Operating Junction Temperature

• Popular TO−220 Package

• High Voltage Capability to 600 V

• Low Forward Drop

• Low Leakage Specified

• Current Derating Specified

• Pb−Free Packages are Available
